2110 IP UpDownCross 12G - Blackmagic
Converters > Digital <> Digital
EAN:9338716010008
₦ 975,070.75
VAT Included
VAT Included
Adcom - Blackmagic
New
Available in 19 days
Blackmagic Professional Converter 2110 IP UpDownCross 12G, 3 Channels of 3G-SDI Input and 3 Channels of Separate 3G-SDI Output
The SMPTE-2110 3 channel HD converter is perfect for rack mounting. With 3 channels of 3G-SDI input and 3 channels of separate 3G-SDI output, you can connect up to 3 3G-SDI video devices to the SMPTE-2110 with a single converter. All 3 channels can be sent over a simple RJ-45 10G Ethernet connection, so you can use standard, low cost CAT-6 Ethernet cables. This model also includes a reference video output synchronized with PTP clock, and there is a front panel LCD for monitoring.
Professional SMPTE-2110 Broadcast Systems
Blackmagic 2110 IP Converters are designed for integrating SDI devices into 2110 IP broadcast systems.
For example, rack mount models can be installed in a rack next to the equipment they are converting.
With Blackmagic Studio cameras, Blackmagic Audio Monitor 12G G3 and SmartView 4K G3 you can build most of your SMPTE-2110 systems without the need for converters.
In addition, almost all Blackmagic SMPTE-2110 IP video devices can be powered remotely!
By adding converters you can easily upgrade all your video equipment to SMPTE-2110 at a low cost. Simply connect a Blackmagic 2110 IP Converter to live production switchers, disk recorders, streaming processors, cameras, TVs and more.
Compliant with SMPTE-2110 IP Video
Blackmagic 2110 IP products are compliant with the SMPTE-2110 IP Video standard, which defines the transport, synchronization and description of 10-bit video, audio and ancillary data over IP networks for broadcast.
They can also re-synchronize SDI inputs to a common PTP clock or lock external devices to the reference output, which is also generated by the PTP clock.
Blackmagic 2110 IP products support SMPTE-2110-20 for uncompressed video, SMPTE-2110-21 for traffic mode and timing, SMPTE-2110-30 for audio and SMPTE-2110-40 for ancillary data.
They also support multicast, which is an efficient way to distribute video, audio and da
